Luojiaohe Bridge Hangrui
杭瑞高速落脚河大桥
Dafang, Guizhou, China
(591) feet high / (180) meters high
443 foot span / 135 meter span
2012



The highest beam bridge on the G56 Hangrui expressway between Bijie and Zunyi, the Luojiao River is a popular river for high spans with bridges to the north and south exceeding 150 meters in height on the Guiyang-Chengdu Railway and on the Guibi 2-lane highway.

The G56 beam bridge has a configuration of 74+135+74 meters. Although the height is approximately 180 meters to the old river level, a downstream dam can reduce the height to approximately 150 meters.



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com





Image by Eric Sakowski / HighestBridges.com









Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



The older Guibi 2-lane highway can be seen one kilometer south of the Lujiaohe G56 Expressway Bridge. Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Luojiaohe Bridge Hangrui satellite image.





Luojiaohe Bridge Hangrui location map.
